Types of Pneumatic Actuators we offer:
Single-Acting Actuators: We offer single-acting actuators that move in a single direction using air pressure and return with springs.
Double-Acting Actuators: To increase control and accuracy, we provide double-acting actuators that move in both directions using air pressure.
Technical Specifications
| Actuation Type | Double-Acting / Single-Acting (Spring Return) |
| Mounting | ISO 5211 Standard |
| Operation | Linear / Rotary |
| Operating Pressure Range | 3 to 10 bar (43.5 to 145 psi) |
| Maximum Pressure | 10 bar (145 psi) |
| Temperature Range | -20°C to +80°C (-4°F to +176°F) |
| Body | Anodized Aluminum |
| Stroke | Adjustable +/- 5° for both open and closed positions |
| End Caps | Epoxy Coated Die-Cast Aluminum |
| Seals | Nitrile (NBR), Viton for high-temperature models |
| Springs | High-Quality Steel |
| Fasteners | Stainless Steel |
