Thermowells
Protect temperature sensors from process conditions while enabling reliable and accurate temperature measurement. Elite Flow Engineering offers thermowells designed for different pressure, temperature, flow and installation requirements across industrial applications.
Tapered Thermowell
Description:
The outer diameter gradually decreases from the base (process connection) to the tip.
Real-Life Application:
The standard for demanding processes. Ideal for high-pressure, high-velocity, and vibrating applications (pipelines, refineries, power plants).
Specification:
Offers superior mechanical strength and rigidity to resist bending from flow (vortex-induced vibration). Has a faster response time than a straight type.
Materials:
Stainless Steel (316/316L), Monel 400, Hastelloy C276, Inconel.
Straight Thermowell
Description:
The thermowell has a uniform outer diameter along its entire insertion length. This is the most basic design.
Real-Life Application:
Best for low-pressure, low-velocity processes. Commonly used in tanks, boilers, and utility lines with minimal flow.
Specification:
Offers good corrosion protection (due to thick wall) but has the lowest mechanical strength and slowest response time to temperature changes.
Materials:
Stainless Steel (304, 316), Carbon Steel, Brass, Monel.
Stepped Thermowell
Description:
Has a larger diameter at the base which “steps” down to a smaller diameter for the rest of the length, usually near the tip.
Real-Life Application:
Used when the fastest possible response time is the most critical factor. Common in process control loops and laboratory settings.
Specification:
The reduced mass at the tip allows for rapid heat transfer to the sensor. Its strength is less than a tapered well but better than a straight one.
Materials:
Primarily Stainless Steel (316, 304), as it’s often used in less corrosive, high-response applications.
Temperature Accessories
Complete your temperature measurement system with reliable accessories designed for accurate monitoring, sensor protection and dependable operation in industrial environments.
Bimetal Dial Thermometer
Description:
Bimetal dial thermometers provide direct temperature indication through a clear analog dial. Their robust construction makes them suitable for continuous temperature monitoring in industrial environments.
Applications:
Commonly used for temperature measurement in pipelines, tanks, process equipment, HVAC systems, utilities and general industrial applications.
